Terminology
PeriodicEvent: An event which occurs periodically on a certain weekday.
Use Case
The user wants to define or update periodic events to store them into a database. The task of the system is to maintain this data persistently.
The user wants to receive a report about the planned events in a 'hourplanning' like format.
Data Structure
WeeklyPeriodicEvent
| Name | Name of the periodic event | Type |
|---|---|---|
TimeStart |
Time at which the event starts (Format is HH:MM) |
Text in Format HH:MM |
HoursDuration |
Duration of the event in hours |
Float |
WeekInterval |
Determines how many weeks are between two event. 1 means every week |
Integer |
WeekOffset |
Determines how many weeks must pass before first event happens. |
Integer |
OnMonday |
Indication, if event is on Monday |
Boolean |
OnTuesday |
Indication, if event is on Tuesday |
Boolean |
OnWednesday |
Indication, if event is on Wednesday |
Boolean |
OnThursday |
Indication, if event is on Thursday |
Boolean |
OnFriday |
Indication, if event is on Friday |
Boolean |
OnSaturday |
Indication, if event is on Saturday |
Boolean |
OnSunday |
Indication, if event is on Sunday |
Boolean |
Activities
Define or Update Periodic Events
The user can define a package and adds the periodic events into the database.
The extent in which the StundenPlan can be created contain the ExtentType 'StundenPlan'.
Request StundenPlan
The user can select a package and request the creation of a full StundenPlan for all items and its descendents within the package.
The report can be created by selecting a certain viewmode and by viewing the properties of a package or of an extent.
The report contains a week-overview with the hours as columns and the weekdays as rows.
Technical implementation
Create a new Assembly called 'DatenMeister.StundenPlan'. The assembly shall contain a DatenMeisterPlugin which creates a type and a form definition. This form definition is automatically loaded.
The plugin has to register a new ExtentType called 'StundenPlan'.
The plugin has to register a special viewmode which is neither a TableForm nor a RowForm.
-
The DatenMeister.WebServer itself has to be capable to handle a plugin-concept for Form Types (besides RowForm and TableForm).
-
The DatenMeister.WebServer itself has to be capable to handle additional JavaScript Files
